Applications
Muddy water transfer, Swimming Pool.
Dewatering of ponds, basement of huge builing.
Power plant, ETP, STP
Used in hotel, hospitals, railways, dairy, chemical ind, sugar, steel, cement, food beverages.
Muddy water transfer, Swimming Pool.
Dewatering of ponds, basement of huge builing.
Power plant, ETP, STP
Used in hotel, hospitals, railways, dairy, chemical ind, sugar, steel, cement, food beverages.
| Capacity | Head | Temperature | HP | Speed | Delivery size | Solid size | Connection | Voltage & Phase | Insulation / Protection | Moter | Cable | Mechanical Seal |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Up to 2000 m³/hr | Up to 70 mtr | Up to 45°C | 3 to 300 | 1440/960/750 rpm | 50 mm To 350 mm | 25 mm to 130 mm | DOI/SD/ATS | 415V, 3 Phase | F' Class, 'H' Class / IP 68 | 4, 6, 8 pole continues duty dry type squirrel cage induction moter | PVC Insulated Double heated copper Conductor Flexible cable | Bi-Direction Twin Mechanical seal with various face combination looking to the application. |
C.I, C.S, S.S.
Impeller, Casing, wear plate with Various M.O.C. Bronze, CF8, CF8M, CD4MCU
